Pump QBW3-40PHFP
Pump QBW3-40PHFP
Contact us for price
Location:California
orCall +1(626)3202070
Description
- Product Name: Sanitary Pneumatic Diaphragm Pump
- Model: QBW3-40PHFP
- Material of Wetted Parts: Stainless Steel 304 (Sanitary Grade)
- Diaphragm Material: Ultra PTFE + Polyether
- Valve Ball Material: PTFE
- Ball Seat Material: Stainless Steel 304
- Inlet & Outlet Diameter: DN40
- Inlet & Outlet Connection: Clamp (50.5)
- Inlet Port Size: 1/2 in
- Chuck Diameter: 50.5 mm
- Particle Diameter: 3.2 mm
- Maximum Flow Rate: 0-9 立方/小时 / 0-9 m³/h
- Maximum Flow: 151 L/min
- Maximum Suction Lift: 0-5 m
- Maximum Suction Depth: 5.48 m
- Maximum Head: 0-84 m
- Outlet Pressure: 8.4 kg
Specifications
| Manufacturer | Hongda |
| Model | QBW3-40PHFP |
| Year | 2025 |
| Condition | New |
| Stock Number | 2 |
